Inductors
Power
SMD Metal composite
Product type
Series
Manufacturer
Information
Datasheet
Industrial
MCS20FC-MP
2x1,6x1mm, 0,24~2,2µH, It:5~1,7A, Is:5,6~1,9A, -40°C~125°C, geschirmt
Industrial
MCS20FC-HC
2x1,6x1mm, 0,47~2,2µH, It:4,5~2,2A, Is:6,1~2,6A, -40°C~125°C, geschirmt
Industrial
MCS25GC-MP
2,5x2x1,0mm, 0,22~4,7µH, It:5,9~1,36A, Is:7,9~1,8A, -40°C~125°C, geschirmt
Industrial
MCS25GD-MP
2,5x2x1,2mm, 0,47~4,7µH, It:4,6~1,61A, Is:5,3~1,9A, -40°C~125°C, geschirmt
Industrial
MCS25GD-HC
2,5x2x1,2mm, 0,47~2,2µH, It:5,8~2,5A, Is:6,8~3,5A, -40°C~125°C, geschirmt
Industrial, Automotive
MCS0420
4x4x2mm, 0,1~10µH, It:12~1,2A, Is:22~2,2A, -55°C~125°C, geschirmt
Industrial
MCS0530
5,4x5,2x3mm, 0,2~10µH, It:18~2,5A, Is:14,5~3,5A, -55°C~125°C, geschirmt
Industrial
MCS0618
7,1x6,6x1,8mm, 0,1~6,8µH, It:18~2,8A, Is:40~3,5A, -55°C~125°C, geschirmt
Industrial
MCS0624
7,3x6,6x2,4mm, 0,1~10µH, It:30~2,5A, Is:50~6A, -55°C~125°C, geschirmt
Industrial, Automotive
MCS0630
7,3x6,6x3mm, 0,22~15µH, It:23~3,5A, Is:40~3A, -55°C~125°C, geschirmt
Industrial, Automotive
MCS1040
11,15x10x4mm, 0,22~47µH, It:30~3,3A, Is:50~3,5A, -55°C~125°C, geschirmt
Industrial
MCS1235
12,8x13,5x3,5mm, 0,1~10µH, It:43~7A, Is:84~13A, -55°C~125°C, geschirmt
Industrial, Automotive
MCS1250
13,5x12,8x5mm, 0,1~10µH, It:55~9A, Is:80~12A, -55°C~125°C, geschirmt
Industrial, Automotive
MCS1265
13,5x12,8x6,5mm, 0,1~68µH, It:60~2A, Is:120~3,5A, -55°C~125°C, geschirmt
Industrial, Automotive
MCS1770
18x17,15x7mm, 0,82~100µH, It:56,5~5A, Is:45~4A, -55°C~125°C, geschirmt
Industrial
CSCA2016D
2x1,6x1mm, 0,24~4,7µH, It:4,2~1A, Is:45~4A, -40°C~105°C, geschirmt
Industrial
CSCA2520D
2,5x2,0x1,2mm, 0,47~4,7µH, It:4~1,3A, Is:45~4A, -40°C~105°C, geschirmt
Industrial, Automotive
ME
2x1,2x1~2x1,6x1mm 0,47~2,2µH, It: 4,2~2,3A, Is:4,5~2,3A -40~125°C, geschirmt
Industrial
MC
1x0,5x0,55~2x1,25x2mm 0,1~1,0µH, It:3,6~0,8A, Is:4,5~0,8A -40~125°C, geschirmt
Industrial, Automotive
MD
1,6x1,6x0,95~4,9x4,9x2mm 0,3~33µH, It:8,8~0,44A, Is:21~0,46A -40~125°C, geschirmt
Industrial, Automotive
MA-H
2x1,6x1~2,5x2x1,2mm 0,22~10µH, It:5~0,75A, Is:7,5~1,1A -40~125°C, geschirmt
Industrial, Automotive
MA
2x1,6x1~2,5x2x1,2mm 0,24~4,7µH, It:3,5~0,95A, Is:4,7~1A -40~125°C, geschirmt
Industrial
MB-H
1,6x0,8x1~2,5x2x1,2mm 0,24~4,7µH, It:3,5~0,8A, Is:4,7~0,37A -40~125°C, geschirmt
Industrial
MB
1,6x0,8x1~2,5x2x1,2mm 0,24~4,7µH, It:3,5~0,5A, Is:4,75~0,37A -40~125°C, geschirmt
Industrial
MPCH0730
6,7x8x3mm, 0,12~0,24µH, It:31~23A, Is:32~19A, -20°C~120°C, geschirmt, flat wire inductor
Industrial
MPCH0740
6,7x8x4mm, 0,15~0,36µH, It:29~23A, Is:31~22A, -20°C~120°C, geschirmt, flat wire inductor
Industrial
MPCH1040
10x11,5x4mm, 0,36~1µH, It:28~17A, Is:24~17A, -20°C~120°C, geschirmt, flat wire inductor
Industrial
MPCH1055
10x11,7x5,5mm, 1,3µH, It:18,5A, Is:17A, -20°C~120°C, geschirmt, flat wire inductor
Industrial
MPCH1060
10x12x6mm, 0,45µH, It:32A, Is:32A, -20°C~120°C, geschirmt, flat wire inductor
Industrial
MPCH1250
12,5x14,3x5mm, 1,5µH, It:21A, Is:21A, -20°C~120°C, geschirmt, flat wire inductor
SMD Ferrite Inductor
Product type
Series
Manufacturer
Information
Datasheet
Industrial
CSS124P
12x12x4,8mm, 3,9~330µH, It:6,5~0,5A, -30°C~100°C, geschirmt
Industrial
CSS125P
12x12x6,0mm, 1,3~1.000µH, It:8~0,4A, -30°C~100°C, geschirmt
Industrial, Automotive
CSS127P
12x12x8,0mm, 1,2~1.000µH, It:9,8~0,55A, -30°C~100°C, geschirmt
Industrial, Automotive
NR
2x2x1~8x8x4mm 0,47~220µH, It:9,6~0,17A, Is:14~0,27A -40~125°C, geschirmt
Industrial, Automotive
NS
10,1x10,1x4,5~12,5x12,5x7,5mm 1~1.500µH, It:9,15~0,44A, Is:18~0,4A -40~125°C, geschirmt
Signal
SMD Wire-Wound Ceramic Inductor
Product type
Series
Manufacturer
Information
Datasheet
Industrial
0402CP
1,19x0,64x0,66mm 1~120nH, It:1,36~0,05A, -40~125°C, High-Q
Industrial
0603CP
1,8x1,12x1,02mm 1,6~390nH, It:0,7~0,1A, -40~125°C, High-Q
Industrial
0805CP
2,29x1,73x1,52mm 2,2~820nH, It:0,6~0,18A, -40~125°C, High-Q
Industrial
1008CP
2,92x2,79x2,03mm 10~4700nH, It:1~0,26A, -40~125°C, High-Q
Industrial
1210C
3,42x2,8x2,3mm 4,7~3300nH, It:0,6~0,05A, -40~125°C, High-Q
Industrial
1812CP
4,95x3,8x3,43mm 82~1200nH, It:1,5~0,48A, -40~125°C, High-Q
Industrial
0805F
2,29x1,91x1,6mm 0,078~27µH, It:2~0,12A, -40~85°C, High-Q
Industrial
1008F
2,92x2,79x2,03mm 0,047~22µH, It:0,65~0,12A, -40~85°C, High-Q
SMD Wire-Wound Inductor
Product type
Series
Manufacturer
Information
Datasheet
Industrial
BR
1,6x0,8x0,7~3,2x2,5x1,7mm 0,2~100µH, It:9,15~0,44A, Is:18~0,4A -40~125°C,
Industrial, Automotive
CB
1,6x0,8x0,8~3,2x2,5x2,5mm 1~1.000µH, It:1,5~0,06A, Is:2~0,025A -40~105°C,
SMD Multilayer Inductor
Product type
Series
Manufacturer
Information
Datasheet
Industrial
CKP
1,6x0,8x0,95~2,5x2,0x1,2mm 0,33~4,7µH, It:1,6~0,35A, -40~85°C,
Industrial
LB
1,6x0,8x0,8~3,2x3,25x2,5mm 1~1.000µH, It:1,1~0,015A, -40~105°C,
Industrial, Automotive
LBM
2x1,6x1,6mm 0,12~220µH, It:0,61~0,065A, -40~105°C,
Industrial, Automotive
LK
1x0,5x0,5~2x1,25x1,25mm 0,047~33µH, It:300~1mA, -40~85°C,
Industrial
CK
1,6x0,8x0,8~2x1,25x1,25mm 0,1~10µH, It:500~50mA, -40~85°C,
Industrial, Automotive
HK
1x0,5x0,5~2x1,25x1mm 1~470nH, It:0,9~0,06A, -40~125°C, hig frequency,
Industrial, Automotive
HKQ
0,6x0,3x0,3~1x0,6x0,5mm 0,6~100nH, It:0,93~0,1A, -40~125°C, high frequency, High-Q
Line Filter
THT vertical
Product type
Series
Manufacturer
Information
Datasheet
Industrial
FVS2424
18x26x30mm, 2,7~120mH, It:2~0,3A, -20°C~105°C, vertical
Industrial
FVS2828
22x31x35,5mm, 3,3~120mH, It:3~0,5A, -20°C~105°C, vertical
Industrial
FVS3535
25x37,5x43,5mm, 2,2~30mH, It:4,5~1,5A, -20°C~105°C, vertical
Industrial
FVU0914
11x16,5x17mm, 0,2~40mH, It:2~0,1A, -20°C~105°C, vertical
Industrial
FVU1016
19x17x22mm, 1~20mH, It:2,9~0,8A, -20°C~105°C, vertical
Industrial
FVU1520
19x27,5x23mm, 8~10mH, It:1~1,2A, -20°C~105°C, vertical
Industrial
FVX2014
18x23x22mm, 1~33mH, It:2~0,3A, -20°C~105°C, vertical
Industrial
SS11VL
14,5x19,5x22mm, 0,9~55mH, It:0,3~3A, -25°C~120°C, vertical
Industrial
SS11V
22x14,5x21,5mm, 0,9~55mH, It:0,3~3A, -25°C~120°C, vertical
Industrial
SS17VA
12x17x15mm, 0,8~30mH, It:0,3~1,7A, -25°C~120°C, vertical
Industrial
SS24V
19x26x31,5mm, 4~60mH, It:2~0,5A, -25°C~120°C, vertical
Industrial
SS28V
22x30x35,5mm, 4,5~60mH, It:2,5~0,8A, -25°C~120°C, vertical
Industrial
SS30V
22,5x31x33mm, 1,3~96mH, It:4,5~0,8A, -25°C~120°C, vertical
Industrial
SS35V
37x26,5x41mm, 2,2~30mH, It:4,5~1,8A, -25°C~120°C, vertical
Industrial
SS38V
41x26,5x42,5mm, 3,8~7,3mH, It:3,5~4,3A, -25°C~120°C, vertical
Industrial
SSB11V
22x14,5x21,5mm, 4,3~9mH, It:1,7~1,3A, -25°C~120°C, vertical
Industrial
SSB28V
22x30x35,5mm, 8~16mH, It:2,5~0,8A, -25°C~120°C, vertical
Industrial
SCR38-J
53x51x35mm, 0,85~1mH, It:35~20A, -25°C~120°C, vertical, toroid
Industrial
SCR47-J
61x59x39mm, 1,6mH, It:35A, -25°C~120°C, vertical, toroid
Industrial
SCF
15x12mm~36x24mm, 3,5~50mH, It:15~1A, -25°C~120°C, vertical, toroid
Industrial
SC-D
23x13mm~25x19mm, 30~100µH, It:5~2A, -25°C~105°C, vertical, toroid
Industrial
SC
23x13mm~34x23mm, 1~8mH, It:5~2A, -25°C~105°C, vertical, toroid
Industrial
SC-GJ
17,5x17x20mm, 0,6~3mH, It:3~2A, -25°C~120°C, vertical, toroid
Industrial
SC-J
27x20mm~44x30mm, 0,5~8mH, It:18~2A, -25°C~105/120°C, vertical, toroid
Industrial
SC-JV
40x25mm, 15~44mH, It:5~2A, -25°C~105°C, vertical, toroid
Industrial
SCR-J
29x29x23mm, 7~25mH, It:5~2A, -25°C~120°C, vertical, toroid
Industrial
SU10VD
18x16x20mm, 10~80µH, It:2~1A, -25°C~120°C, vertical
Industrial
SU16VD
23x19x27,5mm, 10~50µH, It:4~3A, -25°C~120°C, vertical
Industrial
SU9VD
17x17x11mm, 10~40µH, It:0,7A, -25°C~120°C, vertical
Industrial
SU9VF
17x11x17mm, 1,5~10mH, It:0,7~0,2A, -25°C~120°C, vertical
Industrial
SU9V
17x11x17mm, 0,5~18mH, It:1~0,1A, -25°C~120°C, vertical
THT horizontal
Product type
Series
Manufacturer
Information
Datasheet
Industrial
FHS2424
26x26x21mm, 2,7~120mH, It:2~0,3A, -20°C~105°C, horizontal
Industrial
FHS2828
29,5x29,5x24,5mm, 3,3~120mH, It:3~0,5A, -20°C~105°C, horizontal
Industrial
FHU0914
16x17,5x17mm, 0,2~40mH, It:2~0,1A, -20°C~105°C, horizontal
Industrial
SS11H
21x20,5x19,5mm, 0,9~55mH, It:0,3~3A, -25°C~120°C, horizontal
Industrial
SS17HB
17,85x20x13,8mm, 0,8~30mH, It:0,3~1,7A, -25°C~120°C, horizontal
Industrial
SS17HA
16,85x13,8x19mm, 0,8~30mH, It:0,3~1,7A, -25°C~120°C, horizontal
Industrial
SS20H
22x18,5x22mm, 1,8~51mH, It:2~0,3A, -25°C~120°C, horizontal
Industrial
SS21V
20,5x16,5x24,5mm, 0,8~138mH, It:3~0,3A, -25°C~120°C, horizontal
Industrial
SS24H
26x26x21mm, 4~60mH, It:2~0,5A, -25°C~120°C, horizontal
Industrial
SS26V
20,5x26x30mm, 2,8~117mH, It:3~0,5A, -25°C~120°C, horizontal
Industrial
SS28H
30x30x24,5mm, 4,5~60mH, It:2,5~0,8A, -25°C~120°C, horizontal
Industrial
SS35H
37x35x30mm, 2,2~30mH, It:4,5~1,8A, -25°C~120°C, horizontal
Industrial
SSB11H
21x20,5x16mm, 4,3~9mH, It:1,7~1,3A, -25°C~120°C, horizontal
Industrial
SSB28H
30x30x24,5mm, 8~16mH, It:2,5~0,8A, -25°C~120°C, horizontal
Industrial
SSR21H
23x23x14,5mm, 5,5~155mH, It:2~0,3A, -25°C~120°C, horizontal
Industrial
SSR21HS
23x23x14,5mm, 2,9~135mH, It:2~0,3A, -25°C~120°C, horizontal
Industrial
SCR38-JH
53,5x31,5mm, 0,85mH, It:35A, -25°C~120°C, horizontal, toroid
Industrial
SCR47-JH
70x38mm, 0,8mH, It:40A, -25°C~120°C, horizontal, toroid
Industrial
SC-D
34x23mm, 10~60µH, It:20~8A, -25°C~105°C, horizontal, toroid
Industrial
SC-G
17x14mm, 0,6~5mH, It:3~1A, -25°C~105/120°C, horizontal, toroid
Industrial
SC-GS
15x8,5mm, 0,5~2mH, It:3~1A, -25°C~105°C, horizontal, toroid
Industrial
SC
34x24mm~62x35mm, 1~2mH, It:30~10A, -25°C~105°C, horizontal, toroid
Industrial
SC-JH
42x30~51x34mm, 1~2mH, It:20~10A, -25°C~105°C, horizontal, toroid
Industrial
SC-JS
26x12mm, 0,8~2mH, It:3~2A, -25°C~105°C, horizontal, toroid
Industrial
SCR-JH
29x27x23mm, 7~25mH, It:5~2A, -25°C~120°C, horizontal, toroid
Industrial
SU10VFC
18x15,5x15mm, 1~37mH, It:2~0,3A, -25°C~120°C, horizontal
Industrial
SU7VC
15x10x8,5mm, 0,25~12mH, It:1,2~0,2A, -25°C~120°C, horizontal
Industrial
SU9HF
17x15,5x12,5mm, 1,5~10mH, It:0,7~0,2A, -25°C~120°C, horizontal
Industrial
SU9H
17x15,5x12,5mm, 0,5~18mH, It:1~0,1A, -25°C~120°C, horizontal
SMD
Product type
Series
Manufacturer
Information
Datasheet
USB, LVDS, HDMI
SCM2012F
2x1,2x1,2mm, Z:67~600Ohm, It:400~240mA, -40°C~125°C, geschirmt
USB, LVDS, HDMI
MCF
0,65x0,5x0,3~2x1x0,45mm 12~90Ω, It:50~160mA, -55~85°C,
Noise Suppression
SMD Multilayer Bead
Product type
Series
Manufacturer
Information
Datasheet
Industrial, Automotive
BK
0,6x0,3x0,3~2x1,25x1,25mm 10~2.500Ω, It:1,5~0,2A, -55~125°C,
Industrial
BKH
0,6x0,3x0,3~1x0,5x0,5mm 25~1.800Ω, It:0,45~0,115A, -55~125°C,
Industrial, Automotive
BKP
0,6x0,3x0,3~2x1,25x0,85mm 10~470Ω, It:4~0,8A, -55~125°C,
Industrial, Automotive
FB
1,6x0,8x0,8~4,5x3,2x3,2mm 8~2.000Ω, It:7,5~0,5A, -55~125°C,
